Description
The PBF-49 and PBF-51 Vintage set feature sweet high end and classic warm tones, with focused and defined lows. The string-to-string output is balanced by internal compensation and field shaping. The blade design ensures your tone won’t fade from even the most aggressive bends.
PBF Humbuckers are fully sealed and shielded making them sweat-proof, quiet if you touch them, and immune invisible noise from stage lights and studio power supplies. The shielded 4-conductor cable is ready for coil splitting and series or parallel humbucker wiring.
PBF Humbuckers come in black and chrome in balanced versions for neck (PBF-49 rhythm) and bridge (PBF-51treble). Black mounting screws are included (#4-40 x 7/8”).
PBF Vintage Technical Details
Coil Structure:
Dual Parallel Humbucking
Cable Type:
4-Conductor Cable with shield and bare drain
Magnetic Circuit:
2 types of precision CNC milled carbon steel, brass, and copper powered by ceramic (ferrite) magnets
projected for focused aperture
Neck coil South and Bridge coil North
projected for focused aperture
Neck coil South and Bridge coil North
PBF-49 – Neck
- DC Resistance: ~4.8KΩ each coil
- Resonant Frequency: ~3.8KHz
- Sensing Width: 2.01″ [51mm] Max
PBF-51 – Bridge
- DC Resistance: ~5.2KΩ each coil
- Resonant Frequency: ~3.5KHz
- Sensing Width: 2.01″ [51mm] Max
